Aeromotive Fuel Pressure Regulator -6AN Fittings Black


Performance EFI regulator designed for medium to high horsepower applications. This regulators features Aeromotive high-flow design, superb pressure control and legendary durability. On the street and at the track, this pressure regulator has logged more miles, laps and passes than any other performance EFI regulator in the world!

Base pressure adjustable from 40-75 PSI.
Gasoline and alcohol compatible.
Fuel pressure rises on a 1:1 ratio with boost.
1/8 NPT gauge port.
P/N 13109 provides (2) ORB-06 inlet ports and (1) ORB-06 return port.

Pressure Range (psi) = 40-75
Regulator Style = Return
Regulator Location = Inline
Boost/Vacuum Reference Port = Yes
Boost/Vacuum Rise Ratio = 1:1
Gauge Port = Yes
Mounting Bracket Included = Yes
Fittings Included = No
Rebuild able = Yes
Inlet Quantity = One
Inlet Attachment = Female threads
Inlet Size = -6 AN O-ring
Outlet Quantity = One
Outlet Attachment = Female threads
Outlet Size = -6 AN O-ring
Return Attachment = Female threads
Return Fitting Size = -6 AN O-ring
Regulator Material = Aluminum
Regulator Finish = Red / Silver Anodized
Notes:The included boost reference fitting accepts 1/8 in. hose. 1/8 in. NPT plug is also included for the gauge port. Inlet and outlet fittings are not included.

Universal -6 Fittings

More Information
Color Black
Manufacturer Aeromotive
Price 209.28
